Professional finger joint cutter heads
694.008
The CMT professional finger joint cutter head makes the strongest side-to-side joints on all wood types and composites. The tightness of the joint and the maximum surface area for glue application ensure that the joint itself is stronger than an unworked piece of wood. Maximum thickness 47mm.
For use on spindle moulder machines, double-end tenoner and shaper machines.
Suitable for all materials, but ideal on solid wood and panel materials.
Technical details
- Hard aluminium alloy body with high resistance to tensile and yield stress.
- 2 HWM knives 49,6x11,9x1,5mm [Z2].
- Tools for manual feed (MAN).
-
Pins for the automatic positioning of the knives.
Supplied in a solid plastic box.
Details
Safety Tips:
The TW-006 Torque Screwdriver is recommended
for the proper fastening of screws.
The TW-006 Torque Screwdriver is recommended
for the proper fastening of screws.
Variations
Filter
| Item Code | D | B | Z | MAX RPM | MAT |
|
|
|
|
|---|---|---|---|---|---|---|---|---|---|
|
694.008.30
|
105 | 30 | 2 | 7300~11500 | HW | 990.066.00 | 991.067.00 | 695.999.49 | 695.008.01 |
|
694.008.31
|
105 | 31,75 | 2 | 7300~11500 | HW | 990.066.00 | 991.067.00 | 695.999.49 | 695.008.01 |
|
694.008.35
|
105 | 35 | 2 | 7300~11500 | HW | 990.066.00 | 991.067.00 | 695.999.49 | 695.008.01 |
|
694.008.40
|
105 | 40 | 2 | 7300~11500 | HW | 990.066.00 | 991.067.00 | 695.999.49 | 695.008.01 |
|
694.008.50
|
105 | 50 | 2 | 7300~11500 | HW | 990.066.00 | 991.067.00 | 695.999.49 | 695.008.01 |
